Ductless Systems

You probably already know about Samsung’s history of innovation and reliability. But did you also know this includes innovative heating and cooling solutions for your whole house by utilizing a split system HVAC like a ductless mini split system? Ductless systems typically consist of a wall-mounted indoor unit connected to an outdoor unit, and they’re a simple way to heat and cool your home without the ductwork of a traditional central air system.

For people with single rooms or additions that have different heating and cooling needs than the rest of the house, a mini split heat pump, including a ductless mini split system, can be a perfect solution. They are often more efficient and less invasive than a ducted system and offer greater control over the temperature of these types of spaces. Whether it’s one room or many, new construction or a new addition, your Samsung HVAC professional can help you find an efficient solution that’s perfect for you.

AR**TSFABWKNCV

Wind-Free Indoor Ductless Single-Zone High Wall Heat Pump Unit

View Brochure
Model Family: AR**TSFABWKNCV
Purpose: Heat and Cool
Zone Capability: Single Zone
Efficiency SEER: Up to 24.5 SEER
Efficiency EER: Up to 15.5 EER
Efficiency HSPF: Up to 12.5 HSPF
Matching Outdoor Unit: Single-Zone: AR**TSFABWKXCV and AR**TSFACWKXCV
Matching Outdoor Unit: Multi-Zone: N/A
Energy Star Rated: Energy Star Rated
Refrigerant Type: R410A
Number of Fan Speeds: Three fan speeds
Sound Level: 22 to38 dB
Wireless Remote: Yes
Factory Warranty Parts: 10 Year Warranty with Registration
Manufacturer's Stated Benefits:
  • The system has a built in Wi-Fi adapter as standard to allow control remotely
  • 7-segment digital display on front of unit to display temperature and unit status
  • Auto changeover
  • Fast Comfort mode to quickly reach set temperature
  • 24 hour single event timer
  • Single User Mode to reduce energy consumption during low demand operation
  • Air filter cleaning can be done easily without opening the indoor unit
  • Smart install mode - startup system diagnostics operation to ensure system readiness during initial operation
  • The Smart Check automatic error-monitoring system detects and diagnoses problems .
AR**TSFYBWKNCV

Quantum Ductless Single-Zone High Wall Heat Pump Unit

View Brochure
Model Family: AR**TSFYBWKNCV
Purpose: Heat and Cool
Zone Capability: Single zone
Efficiency SEER: Up to 23.5 SEER
Efficiency EER: Up to 13.95 EER
Efficiency HSPF: Up to 12 HSPF
Matching Outdoor Unit: Single-Zone: AR**TSFYBWKXCV
Matching Outdoor Unit: Multi-Zone: N/A
Energy Star Rated: Energy Star Rated
Refrigerant Type: R-410A
Number of Fan Speeds: 3 Fan speeds
Sound Level: 20-37 dB
Wireless Remote: Yes
Factory Warranty Parts: 10 Year Warranty with Registration
Manufacturer's Stated Benefits:
  • Auto restart
  • Sound ON/OFF with wireless controller
  • Motorized vertical auto-swing louver
  • 2-Step Cooling
  • Good Sleep mode
  • Quiet mode
  • Dry mode
  • Dry mode
  • Clean and maintain your filter with ease
AR36BSHUMGMNCV

Max Indoor Ductless Single Zone High Wall Heat Pump Unit

View Brochure
Model Family: AR36BSHUMGMNCV
Purpose: Heat and Cool
Zone Capability: Single zone
Efficiency SEER: 18.6 Seer
Efficiency EER: 9.5 EER
Efficiency HSPF: 10.1 HSPF
Matching Outdoor Unit: Single-Zone: AR36BSHUMGMXCV
Matching Outdoor Unit: Multi-Zone: N/A
Energy Star Rated: No
Refrigerant Type: R-410A
Number of Fan Speeds: Three fan speed settings and auto setting
Sound Level: Quiet operation
Wireless Remote: Yes
Factory Warranty Parts: 10 years compressor, 10 years parts, 1-year limited labor (conditions apply)
Manufacturer's Stated Benefits:
  • Auto-restart after power loss
  • Soft-start compressor minimizing current inrush
  • Washable filter as standard
  • Unit shall be operated via wireless controller (included)

AR**TSFACWKXCV

Outdoor Unit- WindFree™ 2.0 Max Heat®

View Brochure
Model Family: AR**TSFACWKXCV
Purpose: Heat and Cool
Zone Capability: Single zone
Efficiency SEER: Up to 24.5 SEER
Efficiency EER: Up to 15.5 EER
Efficiency HSPF: 12.5 HSPF
Energy Star Rated: Energy Star Rated
Refrigerant Type: R-410A
Sound Level: 45 dB
Compressor: BLDC Rotary
Factory Warranty Parts: 10 Year Warranty with Registration
Factory Warranty Compressor: 10 Year Warranty with Registration
Manufacturer's Stated Benefits:
    AR**TSFABWKXCV

    Outdoor Unit- Wind-free

    View Brochure
    Model Family: AR**TSFABWKXCV
    Purpose: Heat and Cool
    Zone Capability: Single zone
    Efficiency SEER: Up to 24.5 SEER
    Efficiency EER: Up to 15.5 EER
    Efficiency HSPF: Up to 12.5 HSPF
    Energy Star Rated: Energy Star Rated
    Refrigerant Type: R-410A
    Sound Level: as low as 45 B
    Compressor: BLDC Rotary
    Factory Warranty Parts: 10 year parts warranty
    Factory Warranty Compressor: 10 year compressor warranty
    Manufacturer's Stated Benefits:
      AR**TSFYBWKXCV

      Outdoor Unit- Quantum

      View Brochure
      Model Family: AR**TSFYBWKXCV
      Purpose: Heat and Cool
      Zone Capability: Single zone
      Efficiency SEER: Up to 23.5 SEER
      Efficiency EER: Up to 13.95 EER
      Efficiency HSPF: Up to 12 HSPF
      Energy Star Rated: ENERGY STAR® labeled
      Refrigerant Type: R-410A
      Sound Level: 45 dB
      Compressor: BLDC Rotary
      Factory Warranty Parts: 10 Year Warranty with Registration
      Factory Warranty Compressor: 10 Year Warranty with Registration
      Manufacturer's Stated Benefits:
        AJ0***BXJ2CH/AA

        FJM - Free Joint Multi Outdoor

        View Brochure
        Model Family: AJ0***BXJ2CH/AA
        Purpose: Heat and Cool
        Zone Capability: Multi zone
        Efficiency SEER: Up to 18.0 SEER
        Efficiency EER: Up to 11.1 EER
        Efficiency HSPF: Up to 9.5HSPF
        Energy Star Rated: N/A
        Refrigerant Type: R-410A
        Sound Level: 48-51 dB
        Compressor: Twin BLDC Rotary Inverter
        Factory Warranty Parts: 10 year parts warranty
        Factory Warranty Compressor: 10 year compressor warranty
        Manufacturer's Stated Benefits:
        • Soft-start to reduce current demand during compressor start
        • Auto-restart after power loss
        • The outdoor unit shall be galvanized steel with a baked on powder coated finish for durability
